- Overview
- Battery Balance Connector: JST-XH
Specs
Battery Type: Li-Po
Battery Voltage: 7.4V
Capacity: 800mAh
Cell Configuration: 2S1P
Connector Type: JST
Hard Case: No
Height: 0.5 in (12.5mm)
Length: 2.7 in (69mm)
Maximum Burst Discharge Current: 40A
Maximum Burst Discharge Rate: 50C
Maximum Charge Current: 4A
Maximum Charge Rate: 5C
Maximum Continuous Discharge Current: 24A
Maximum Continuous Discharge Rate: 30C
Normal/Standard Charge Current: 0.8A
Normal/Standard Charge Rate: 1C
Watt Hours: 14.8
Weight: 1.5 oz (43.6g)
Width: 1.0 in (26mm)
Wire Gauge: 20 AWG - Specs
Product Specifications
Part Number VNR25024 Battery Chemistry LiPo Battery Voltage 7.4V (2-cell) Capacity mAh 800mAh Discharge Rate 30C Connector Type JST Battery Balance Connector JST-XH Battery Type Li-Po Battery Voltage 7.4V Capacity 800mAh Cell Configuration 2S1P Connector Type JST Hard Case No Height 0.5 in (12.5mm) Length 2.7 in (69mm) Maximum Burst Discharge Current 40A Maximum Burst Discharge Rate 50C Maximum Charge Current 4A Maximum Charge Rate 5C Maximum Continuous Discharge Current 24A Maximum Continuous Discharge Rate 30C Normal/Standard Charge Current 0.8A Normal/Standard Charge Rate 1C Watt Hours 14.8 Weight 1.5 oz (43.6g) Width 1.0 in (26mm) Wire Gauge 20 AWG - Reviews
