Traxxas XO-1 1/7 AWD Brushless RTR Supercar with TSM and Link

Traxxas is The Fastest Name in Radio Control®. For over 30 years Traxxas has been pushing the performance envelope; leading the industry with technology and innovation. Our passion for cutting edge design, precision, and quality culminates into one vehicle that could only come from Traxxas. Lightning quick steering response and AWD traction make XO-1 unlike anything you have ever driven before. Belted slick tires and functional aerodynamics keep you glued to the pavement. 0-60 in 2.3 seconds. 0-100 in 4.92 seconds. Top speed over 100mph! Simply put, the XO-1 is the most extreme Ready-To-Race® radio controlled supercar in the world.

Supercars are known for their artful, purpose-driven design and insane horsepower and performance. When Traxxas engineers set out to build the XO-1, it had to look good and drive at over-the-top speed. To complement the aerodynamic design and put it to good use, they went for massive power. The XO-1 required a brushless system that could handle and deliver the necessary 6s LiPo power to destroy all speed limits. From the factory, the XO-1 puts out massive acceleration and true supercar performance that simply cannot be touched. It’s all courtesy of the high-powered Traxxas Big Block brushless motor and 6S-ready electronic speed control. You wouldn’t expect anything less from The Fastest Name in Radio Control.

• XO-1 reaches speeds in excess of 100mph with the included accessories!*
• 0-60 mph in 2.3 seconds and 0-100 mph in 4.9 seconds!
• 50+mph out of the box!
• Traxxas Stability Management System® (TSM)
• Aerodynamic, sleek ProGraphix® multi-colored painted body with functional rear wing
• Powered by the Castle Mamba Monster Extreme Power System
• Mamba Monster Extreme electronic speed control with integrated capacitor pack
• Exclusive Traxxas® Big Block 1717 brushless motor (1650 Kv), Powered by Castle
• Computer optimized aerodynamics
• Front splitter
• Included accessory splitter accepts right and left canards for added high-speed stability
• Smooth chassis underside maximizes aerodynamic efficiency
• Left and right tunnels with incorporated NACA motor cooling duct
• Rear diffuser
• Adjustable height body posts with pivoting body washers
• Splined Steel (SS) driveshafts
• Silicone dust boots
• Nickel plated/hardened steel shafts
• Oversized 6mm stub axles.
• Large 6x12mm rubber-sealed ball bearings
• Heavy-duty 17mm splined blue-anodized aluminum hex hubs and wheel nuts
• Sealed, silicone-filled limited slip differentials with 5mm output shafts
• Exclusive Traxxas Cush Drive™ system absorbs drivetrain shocks
• Stout 8mm thick Mod 1.0 (25.4 pitch) pinion and spur gears
• Factory installed gearing: 14-tooth pinion gear and 46-tooth spur gear
• Includes optional 100mph gearing: 34-tooth pinion gear and 46-tooth spur gear
• Dark titanium-anodized 3mm 6061-T6 aluminum upper and lower chassis plates
• Blue-anodized 6061-T6 aluminum motor mount
• Precision gear mesh adjustment screw for quick and accurate gear mesh settings
• Blue-anodized 6061-T6 aluminum C-Hubs
• Blue-anodized 6061-T6 aluminum steering blocks
• Blue-anodized 6061-T6 aluminum rear hub carriers
• Blue-anodized 7075-T6 aluminum front and rear shock towers
• Blue-anodized 6061-T6 aluminum front and rear bulkhead tie bars
• Hard-anodized aluminum PTFE-coated GTR shocks, performance tuned with 1.6 rate blue springs
• Dual-bellcrank steering with integrated servo saver
• Specially engineered belted slick tires (1.7" wide front, 2" wide rear)
• Speed rated (118+mph)
• Black-chrome Split-Spoke wheels
• Contoured, molded tire inserts
• TQi 2.4GHz High-Output radio system with Traxxas Link model memory and factory installed Traxxas Link™ Wireless Module
• Model memory and drive effects are accessible via the Traxxas Link Application for Android, Apple iPhone, iPod touch, iPad or iPad mini
• Factory installed TQi Traxxas Link Wireless Module connects the TQi transmitter with the powerful functionality of an Android, iPhone, iPod touch, iPad or iPad mini
• Automatically stores and loads settings for up to 30 Traxxas Link-enabled models—just switch on and drive, "model selection" is not required.
• Multi-Function knob
• Adjustable steering and throttle percentage (dual rates)
• Adjustable steering and throttle sensitivity (exponential)
• Adjustable steering and throttle end points
• High 13ms frame rate and near-zero latency for responsive control
• Telemetry enabled 5-channel micro receiver with dual channel-1 inputs
• Integrated telemetry sensors relay RPM, voltage, and temperature data to the TQi transmitter
• 2075 digital high-torque, ball bearing steering servo delivers 125 oz-in torque & 0.16-sec transit time
• Waterproof, o-ring sealed receiver box with integrated servo mount
• *100+mph requires:
• Installing the included optional 34-tooth pinion gear and 46-tooth spur gear
• Unlocking the electronic speed governor through the TQi radio utilizing an Android, iPhone, Pod touch, iPad or iPad mini
• Scalable battery compartments from NiMH packs to brutal 6S LiPo power
• Two selectable length options: 135mm and 155mm
• Two selectable height configurations using the included hold-downs
• Eight selectable height configurations using optional expansion kit

Length: 27 inches (686mm)
Front Track: 11.61 inches (295mm)
Rear Track: 11.81 inches (300mm)
Center Ground Clearance: 0.59 inches (15mm)
Weight: 8.6 lbs (3.9 kg) (w/o batteries) 10.3 lbs (4.67 kg) (with batteries)
Height (overall): 5 inches (127.5mm)
Wheelbase: 15.91 inches (404mm)
Front Shock Length: 3.27 inches (83mm)
Rear Shock Length: 3.39 inches (86mm)
Front Tires (pre-glued): Belted Slick Front (4.29" x 1.7")
Rear Tires (pre-glued): Belted Slick Rear (4.29" x 2")
Front Wheels: 3.3" Split-Spoke™ (black-chrome) with 17mm splined hex
Rear Wheels: 3.3" Split-Spoke™ (black-chrome) with 17mm splined hex
Speed Control Type: Castle Mamba Monster Extreme Forward/Reverse/Brake
Motor (electric): Traxxas Big Block Brushless (1650 Kv), Powered by Castle
Transmission: Single-Speed
Overall Drive Ratio: 9.36 (stock, out-of-box)
Differential Type: Sealed Hardened Steel Bevel
Gear Pitch: Module 1.0
Chassis Structure/Material: 3mm Plate, Dual Plane, 6061-T6 Aluminum
Brake Type: Electronic
Drive System: Shaft-Driven 4WD
Steering: Bellcrank
Transmitter: TQi™ 2.4GHz Radio System with Traxxas Link Wireless Module
Receiver: Traxxas Stability Management® Receiver ( tra6533 )
Top Speed: 100+mph
Skill Level: 10
Battery Tray Dimensions: 155mm x 50mm x 29mm (adjustable height and length)
Required Batteries & Charger: Two Traxxas Power Cell LiPo Batteries (LiPo, 3-Cell 5,000 mAh), 4 "AA" (transmitter), LiPo Battery Charger
Castle Creations Mamba Monster Extreme Speed Control:
When the goal is 100+mph, "off the shelf" is out of the question. Traxxas partnered with Castle Creations to develop the Mamba Monster Extreme power system specifically for the unique power requirements of the XO-1. The proven Mamba Monster system has been enhanced for higher output when used with 6S LiPo power. From its integrated capacitor bank to the proprietary software created just for XO-1, the Mamba Monster Extreme speed control represents the state-of-the-art in big-volt power delivery.

Traxxas Big Block Brushless Motor:
The ultimate brushless powerhouse! Custom tuned for the XO-1, the Traxxas Big Block motor features a finned, heat-dissipating can, oversized premium-quality bearings, sintered Neodymium magnets, and superior electromagnetic design. The Big Block brushless motor invites "cubic inches" to the party for massive acceleration and true supercar performance with the largest brushless motor ever offered in a Ready-To-Race model.

Traxxas Stability Management® (TSM):
Traxxas TSM gives you all the benefits modern electronic stabilization has to offer without intruding on your driving fun or introducing unexpected side effects that can be found on other systems such as drastically reduced turning radius, braking assistance that times out (quits), throttle restrictions, and an overall disconnected driving feel. Traxxas engineers developed superior tuning algorithms that run on high-speed, precision electronic components to create a system that works invisibly, in the background, without ever limiting your throttle. TSM can be fine tuned (or turned off) for different surfaces by simply adjusting the multi-function knob on the TQi transmitter, or by adjusting the slider in the Traxxas link app. The result is that you are driving faster, with more ease, and having more fun. In fact, you may not even realize how much TSM is helping you until you turn it off and test your driving skills without it!

Advanced TQi 2.4GHz Radio System with Traxxas Link Wireless Module:
Traxxas models deserve the world's most advanced Ready-To-Race® radio system. The radio system is the sole connection between the driver and machine. It has to be precise, comfortable, powerful, and reliable. The all-new Traxxas® TQi™ radio system arrives with a full complement of tuning features; long-range, high-output, 2.4GHz signal, and proven Traxxas reliability for rock-solid performance. It's so advanced; it doesn't even need an external antenna. However, the most important new feature may already be in your pocket. The XO-1's TQi transmitter is equipped with an accessory Traxxas Link Wireless Module that turns your Android, iPhone®, iPod touch®, iPad® or iPad® mini into a powerful tuning tool for your Traxxas model. The device display combines with the Traxxas Link™ App to deliver an intuitive, high-definition, full-color graphical user interface that unlocks the mysteries of optimizing your radio system for ultimate vehicle control.

Real-Time Telemetry:
Traxxas Link collects and records real-time telemetry data as you drive. The Traxxas Link dashboard comes to life showing you speed, battery voltage, RPM, and temperature. The application automatically detects and recognizes Traxxas Link sensors for easy set up and configuration. The dashboard is fully customizable with either dial or digital readout gauges. Up to nine gauges can be displayed at once. Set threshold warnings and log maximums, minimums, or averages. Use the recording function to document your dashboard view, with sound, so that you can keep your eyes on your driving and not miss a single apex. If you forget to record, simply touch Instant Replay anytime to capture the previous minute of fun and unexpected triumphs. The recordings can be named, saved, and shared with others.

Intuitive Android, iPhone and iPod touch Interface:
Traxxas Link makes it easy to learn, understand, and access the powerful tuning options built into every Traxxas TQi radio system. Control your Drive Effects settings such as steering and throttle sensitivity; steering percentage; braking strength; and throttle trim by simply touching and dragging the sliders on the screen, or enabling the Multi-Function knob on the transmitter. Everything happens live, on-the-fly, giving you instant feedback on your changes.

Speed-Rated Belted Tires:
Specially developed for high-speed use, XO-1's slick tires are the first to be rated for 100+mph. Zero-stretch belting reinforces the soft-compound rubber, and molded inserts support the tread. Black-chrome Split-Spoke wheels set off the 17mm blue-anodized nuts that secure them, and the wheels extra-wide tire mounting area assures 100mph reliability.

Scalable Battery Compartments:
XO-1 can accommodate a variety of battery configurations and sizes with its unique, scalable battery compartments and quick-release hold-downs. The compartments' rear bulkhead can be positioned for 135mm and 155mm pack lengths. The hold-downs can be flipped to hold 23mm and 25mm pack heights. With the optional expansion clips, 38mm to 43mm tall packs can be installed. Removing and installing batteries is easy; just flex the latch open to release the pack, and snap the hold down into the latch to lock it into place.
