- Overview
Overview
This R/C assembly car kit replicates the Lancia Rally 037 as raced in the early 1980’s. The highly detailed body is made of durable ABS plastic and it sits on top of Tamiya’s TA-02 S chassis.
The Lancia body is specifically mounted on a TA-02 variant. Known as the TA-02S, this version exhibits a short-wheelbase to accommodate the scale form of the real sports car. It features a tub chassis with 4-wheel, fully independent suspension coupled with a rear ball differential and a front gear type differential.Includes:
- Lancia 037 1/10 scale Rally Car Kit
- Motor, ESC
- Tires, Wheels,
- 21T Pinion Gear, 74T Spur Gear
- Body Accent and Sponsor Decals
- ABS Plastic Body
- Instruction Manual
Requires:
- 2-channel radio system
- Battery pack + compatible charger
- PS sprays
- 8x AA batteries
- Tools
features
- The injection molded body offers a highly realistic recreation of the 037. Comes with metal-plated light cases for headlights, taillights and fog lamps. Side mirrors and windshield wipers are made using separate parts.
- The interior features depictions of driver & co-driver, plus dashboard.
- The TA02S chassis is a shaft-driven 4WD unit with bathtub frame, a rear ball diff and front gear diff.
- Four-wheel independent double-wishbone suspension is paired with CVA oil shock dampers.
- New front bumper and sticker sheet.
- Compatible with standard Type 540 motors.
- Includes 540-Type brushed motor.
- separate plastic sheet with driver and passenger
- reverse may be disabled
- Plastic with brushed chrome finished wheels
Wheelbase: 10.2" (260mm)Specs
Length: 15.2" (387mm)
Width: 6.9" (176mm)
Height: 3.9" (100mm)
Chassis: Tub design TA02-S short wheelbase
Drive: Four wheel
Motor: 540 size brush equipped
Electronic Speed Control: Tamiya TBLE-02 with reverse and braking,
Suspension: Fully independent double wishbone
Differentials: Front gear type, rear ball type
Body: ABS plastic with separate clear plastic piece for windows
Wheels: 0.94" (24mm) wide; 1.9" (48mm) diameter
Tires: Radial tread, 0.94" (24mm) wide, 2.5" (65mm) outer diameter with foam inserts
Caster: Adjustable front only
Camber: Non-Adjustable- Specs
Product Specifications
Part Number TAM58654 Scale 1/10 Drivetrain 4WD Kit Type Unassembled Kit Wheelbase 10.2" (260mm) Length 15.2" (387mm) Width 6.9" (176mm) Height 3.9" (100mm) Chassis Tub design TA02-S short wheelbase Drive Four wheel Motor 540 size brush equipped Electronic Speed Control Tamiya TBLE-02 with reverse and braking, Suspension Fully independent double wishbone Differentials Front gear type, rear ball type Body ABS plastic with separate clear plastic piece for windows Wheels 0.94" (24mm) wide; 1.9" (48mm) diameter Tires Radial tread, 0.94" (24mm) wide, 2.5" (65mm) outer diameter with foam inserts Caster Adjustable front only Camber Non-Adjustable - Reviews
