- Overview
FEATURES:
Chassis: 6061-T6 aluminum, .16" (4mm) thick, blue in color, heavy duty braces, long wheelbase configuration
Drive: Four wheel shaft driven with Revo spec driveline including sealed driveshafts, pivot balls and axle carrier
Wheelie Bar: 4 snap-in adjustment positions to control degree of wheelie action, easily removable if additional control isn't needed
Radio: Traxxas TQi 2.4GHz high output with Traxxas Link automatic model recognition, telemetry enabled 5-ch micro receiver with dual channel 1 inputs, included Traxxas Link Wireless Module offers Bluetooth connectivity and enables model to be tuned from an iPhone or iPod Touch (Traxxas Link App must be downloaded if wanting to use an iPhone or iPod Touch) telemetry sensors for RPM, speed temperature, and voltage
Engine: Traxxas .20 cu in (3.3cc) racing engine w/Slide Valve Carburetor, 12mm diameter IPS crankshaft, high volume dual stage air filter
Starter: EZ-Start electric starting system with Traxxas's exclusive Smart-Start technology that monitors critical starting functions, sensing and diagnosing potential problems for easy starting every time
Battery: Traxxas Power Cell
Battery Charger: 110V AC powered
Exhaust: Maxx Resonator dyno tuned dual chamber polished tuned pipe
Brake: Semi metallic, giant 1.6" (42mm) diameter
Tires: 6.3" (160mm) outer diameter, 3.8" (96.5mm) inner diameter all terrain Maxx
Wheels: Hurricane chrome wheels 3.8" (96.5mm) diameter, 2.75" (70mm) wide, 14mm hex size
Transmission: Revo-Spec forward only two speed autoshifting with skid plate, optional reverse kit sold separately
Differential: Revo-Spec sealed front and rear
Ball Bearings: Full set, rubber sealed
Fuel Tank: 4.2oz (125cc)
Body: Trimmed and painted
Shocks: Eight oil-filled Ultra with rubber pressure badders and double O-ring seals, up to ten shock mounting positions, nearly 4" (102mm) travel
Caster: Adjustable, caster/toe-in refers to the angle of the front suspension when viewed from the side of the car in relation to the chassis
Camber: Adjustable, camber refers to the angle of the tops of the tires from vertical when viewed from front or behind vehicle
Suspension: Sealed pivot ball WideMaxx independent
Steering: Heavy duty bellcrank steering with integrated servo saver
Skid Plates: Heavy-duty plastic, front and rearINCLUDES:
New T-Maxx RTR 3.3 truck, TRX 3.3 engine, EZ Start electric starter, docking base, EZ Start battery, charger, fuel bottle, extra glow plug, metric hex hardware, air filter, two decal sheets setup DVD, antenna tube, painted body, illustrated instruction manual, TQi 2.4GHz radio system, installed telemetry sensors for RPM, speed, temperature, and voltage
REQUIRES:
AA Batteries: 4 for transmitter, 4 for battery box
Fuel: 10%-20% or 33% Top Fuel from Traxxas, 20% recommended for break-in
Track EquipmentSPECS:
Chassis;
Length: 21" (539mm)
Front Track: 16.4" (417mm)
Rear Track: 16.5" (417mm)
Height: 11" (277mm)
Center Ground Clearance: 4" (106mm)
Wheelbase: 13.2" (335mm)
Wheel Diameter: 3.8" (97mm)
Transmission: Auto two-speed, forward
Body;
Length: 19.6" (499mm)
Width: 6.3" (158mm) ahead of front wheels, narrowest point
Width: 8.2" (209mm) at rear wheels, widest point
Height: 5.7" (145mm)COMMENTS:
Available in the following body colors;
Blue, TRAD60BB
Red, TRAD60RR
Black, TRAD60LL
White, TRAD60WW- Specs
Product Specifications
Part Number TRA49077-1 Scale 1/10 Drivetrain 4WD Kit Type RTR - Reviews
