You'll never have to set charge preferences for a Spektrum Smart battery until you want to. When a Spektrum Smart LiPo battery is connected to a Spektrum Smart charger, unique parameters and health of that Smart LiPo battery upload from the Smart memory microchip integrated into the battery. Through the charger, you can view and set preferences, such as charge rates, so that all you have to do to charge the pack every time is press the charger "Start" button. Smart technology takes care of the rest.
Our new Spektrum Smart 50C LiPos come in a variety of popular sizes and are ready to drop into your RC aircraft for better performance, power, and reliability. These are the perfect packs for high performance models and power systems and a great upgrade to get more punch and power on nearly any setup.
Spektrum Smart LiPo Batteries Store Unique Data, Such As:
Battery Brand
Battery Type
Battery Capacity
Battery C Rating
Individual Cell Voltage
Battery Temperature
Charge/Discharge Cycles
Spektrum Smart LiPo batteries also maintain an error log including the number of over-heat, over-discharge and over-charge incidents which can be helpful data in assuring that the battery you've chosen is right for the application. A Smart Battery uploads its charge parameters to a Spektrum Smart Charger automatically making charging as simple as pressing the "Start" button. The charge rate of every Smart Battery is customizable, allowing you to take full advantage of packs with faster charge ratings.features
- Integrated microchip stores unique parameters for each battery
- Smart discharge allows batteries to automatically discharge to a safe voltage
- Save time and hassle, while improving battery life
- Powerful 50C continuous discharge rating to deliver high performance and longevity
- Protective outer metal alloy sheet helps dissipate heat, hold battery shape, and increase durability
- No soldering required, equipped with IC3 and IC5 Connectors that are compatible with EC3 and EC5
- 50C battery packs are available in a variety of capacities and cell counts that are perfect for almost any application
Application: AircraftSpecs
Battery Balance Connector: JST/XH
Battery Type: LiPo (3.7V per cell)
Battery Voltage: 14.8V
Capacity: 3200mAh
Charge Protection Circuitry: Yes
Connector Type: IC3
Hard Case: No
Maximum Charge Rate: 3C
Maximum Continuous Discharge Current: 50C
Number of Cells: 4
Product Height: 1.0" (25.4mm)
Product Length: 5.3" (135mm)
Product Weight: .63lbs (290g)
Product Width: 1.6" (42mm)
Technology: Smart
Wire Gauge: 12 AWG- Specs
Product Specifications
Part Number SPMX32004S50 Battery Chemistry LiPo Battery Voltage 14.8V (4-cell) Capacity mAh 3200 Discharge Rate 50 Application Aircraft Battery Balance Connector JST/XH Battery Type LiPo (3.7V per cell) Battery Voltage 14.8V Capacity 3200mAh Charge Protection Circuitry Yes Connector Type IC3 Hard Case No Maximum Charge Rate 3C Maximum Continuous Discharge Current 50C Number of Cells 4 Product Height 1.0" (25.4mm) Product Length 5.3" (135mm) Product Weight .63lbs (290g) Product Width 1.6" (42mm) Technology Smart Wire Gauge 12 AWG - Reviews
