Overview
Customers looking for a quality crawler in the 1:18 segment have struggled to find one with a reasonable price and truly RTR. Until now the market has offered either a very poor quality toy-level one, or too expensive and complicated to start with. Not everyone wants to spend time to build, paint and trim their crawler, but they are looking for an easy to carry size vehicle which is already built and has the same chassis design and functionality as bigger vehicles. Additional features such as the realistic scale like body, alloy oil filled shock absorbers, lights, hub weight blocks, 3 speed electronic transmission and great crawling performance mean it can be used at home, at the office or outside and offer tons of enjoyment.
features
- Class leading scale detail:
- LED on/off function is controlled from the remote
- LED's for reverse and brakes work in conjunction with ESC brake and reverse function
- Front and Rear molded bumpers
- Light Buckets
- Spare tire carrier with fully functional spare tire
- Injection molded windshield wipers, door handles and reverse induction hood cowl
- Realistic tire tread design
- Military style off-road wheels
- Aluminum oil-filled shocks with coil over springs
- Solid axle front and rear with lockers - provides the utmost traction for tackling the harshest of obstacles.
- 3 Speed Electronic Throttle Control Function:
- 3 speed user selected throttle mode through switch on remote control
- Great for beginners or to help create a more realistic crawl mode for those tougher obstacles.
- Added Value:
- USB Charger allows you to charge anywhere.
- 30 minute charge time - 1/1 charge time to drive time!
- No assembly required - Charge and Go!
- Stealth like driving experience - Engineered to be ultra quiet as you explore the outdoors.
Approximate Assembly Time: No assembly required - true RTRSpecs
Battery: 700mAh 2-cell Li-ion w/JST connector (included)
Body: Scale, painted
Motor Size: 180 51T reverse rotation
Motor Type: Brushed
Charger: USB Charger
Chassis Structure / Material: Steel Ladder Frame with Nylon Composite Crossmembers
Drive System: Shaft Driven 4WD
Completion Level: Ready-To-Run
Differential: Locked
Radio: 2.4GHz
Steering servo: Included
Size/Scale: 1:18
Speed Control: Included - fully proportional forward & reverse
Suspension: Solid Axle 4-Link
Vehicle Type: 4WD "Scale" Rock Crawler
Water-Resistant: Yes
Wheel Type: Black Molded
Shock Type: 55mm(2.16 in) Oil filled, partial alloy (4)
Brake Type: Electronic
Steering: 9g servo
Transmission: 3 speed electronic switch, Remote Shifting
Lights: Front & Rear LED (controllable)
Approach Angle: 55°
Departure Angle: 60°
Breakover Angle: 44°
Max climb angle: 50°
Max tilt angle: 45°
Axle articulation: 25°
Front Track: 119mm (4.68 in)
Rear Track: 119mm (4.68 in)
Ground clearance: 44mm capable: (1.73")
Ground clearance at standard ride: height 40mm: (1.57")
Axle ground clearance: 21mm: (0.83")
Height: 136mm (5.35 in)
Length: 263mm (10.30 in)
Width: 120mm (4.72 in)
Wheelbase: 150mm (5.90 in)
Front Shock Length: 55mm (2.16 inches)
Rear Shock Length: 55mm (2.16 inches)
Front Wheels: 25.4 x 15mm (1 x 0.6 inches)
Rear Wheels: 25.4 x 15mm (1 x 0.6 inches)
Front Tires: 54x 21mm (2.13 x 0.83 inches)
Rear Tires: 54x 21mm (2.13 x 0.83 inches)
Wheel Hex Size: 7mm
Battery Tray: 48 L x 30 W x 22mm H
Weight Blocks weight: 46g(1.62oz)
Running weight: 470g (1.03lbs)
Weight without battery: 442g (0.98lbs)
Body Weight with lights: 80g (2.82oz)
Pinion: 12T
Spur Gear: 24T
Transmission: 3 speed electronic switch, Remote Shifting
Drivetrain ratio: 35.5:1
Axle gearing: 2:1- Specs
Product Specifications
Part Number PHT1801B Scale 1/18 Drivetrain 4WD Kit Type RTR Approximate Assembly Time No assembly required - true RTR Battery 700mAh 2-cell Li-ion w/JST connector (included) Body Scale, painted Motor Size 180 51T reverse rotation Motor Type Brushed Charger USB Charger Chassis Structure / Material Steel Ladder Frame with Nylon Composite Crossmembers Drive System Shaft Driven 4WD Completion Level Ready-To-Run Differential Locked Radio 2.4GHz Steering servo Included Size/Scale 1:18 Speed Control Included - fully proportional forward & reverse Suspension Solid Axle 4-Link Vehicle Type 4WD "Scale" Rock Crawler Water-Resistant Yes Wheel Type Black Molded Shock Type 55mm(2.16 in) Oil filled, partial alloy (4) Brake Type Electronic Steering 9g servo Transmission 3 speed electronic switch, Remote Shifting Lights Front & Rear LED (controllable) Approach Angle 55° Departure Angle 60° Breakover Angle 44° Max climb angle 50° Max tilt angle 45° Axle articulation 25° Front Track 119mm (4.68 in) Rear Track 119mm (4.68 in) Ground clearance 44mm capable: (1.73") Ground clearance at standard ride height 40mm: (1.57") Axle ground clearance 21mm: (0.83") Height 136mm (5.35 in) Length 263mm (10.30 in) Width 120mm (4.72 in) Wheelbase 150mm (5.90 in) Front Shock Length 55mm (2.16 inches) Rear Shock Length 55mm (2.16 inches) Front Wheels 25.4 x 15mm (1 x 0.6 inches) Rear Wheels 25.4 x 15mm (1 x 0.6 inches) Front Tires 54x 21mm (2.13 x 0.83 inches) Rear Tires 54x 21mm (2.13 x 0.83 inches) Wheel Hex Size 7mm Battery Tray 48 L x 30 W x 22mm H Weight Blocks weight 46g(1.62oz) Running weight 470g (1.03lbs) Weight without battery 442g (0.98lbs) Body Weight with lights 80g (2.82oz) Pinion 12T Spur Gear 24T Drivetrain ratio 35.5:1 Axle gearing 2:1 - Reviews
