- Overview
Overview
With the Losi® Rock Rey Kit, option parts come standard so you can customize the vehicle how you want. You have complete freedom to accessorize and hop up your vehicle to your liking. With a new roll cage that resembles full-scale rock racers, this basher is ready to go head-to-head with the best. Its new front-end geometry adds the needed handling for rock racing while taking advantage of the Baja Rey's rear-loading battery and bottom-loading motor. The Rock Rey is most at home in rocky terrain-the rougher the better. So go ahead let it rip.
Includes:
- (1) Losi® Rock Rey™ Truck Kit
- (1) Clear Body (with Headlight Receptors Installed)
- (1) Servo Arm with Metal Inserts
- (2) Adjustable Turnbuckles
- (2) Aluminum Upper Links
- (1) Aluminum Axle Housing Upper Track Rod Mount
- (1) 30 Weight Shock oil
- (4) Wheels and Tires
- (1) 10T 1.0 Module Pinion Gear
- (1) User Manual
Requires:
- Motor
- Electronic Speed Control
- Servo
- Radio System
- 7.4V 5000mAh 2S or 11.1V 5000mAh 3S LiPo Battery
- Charger
- Paint
- Tools
- Glue
features
- Build It Your Way
- 4WD Independent Front Suspension with Solid 4 Link Rear Axle
- Option Parts Included
- Rear-Loading Battery Door
- Aluminum Chassis and Injection Molded Composite Roll Cage
- LED Light Bar
- Metal Inserted Servo Horns
- 2.2" x 5.8" Maxxis Creepy Crawler LT Tires
- HD Metal Gear Transmission
- Headlight Receptors
- Preset Motor Plate
- Multiple piece polycarbonate body with detailed interior
- Oil-filled shocks
Approximate Assembly Time: 10-15 HoursSpecs
Ball Bearings: Yes
Batteries: 2S 5000mAh LiPo with EC3⢠Connectors (Sold Separately)
Body: Clear, Polycarbonate
Brakes: Electronic
Charger: (Sold Separately)
Chassis: 3.5mm Plate, 6061-T6 Aluminum
Completion Level: Kit
Differential: Locked Rear, Gear Diff Front and Rear-Sealed
Drivetrain: 4WD
Front Track: 12.75 in (323.8mm)
Gear Pitch: 1.0 Module
Ground Clearance: 2.2 in (55.9mm) at rear diff
Height: 8.75 in (222.3mm)
Length: 20.75 in (527mm)
Motor Size: 550 (Sold Separately)
Motor Type: Non-Sensored Brushless (Sold Separately)
Pinion: 10T
Radio: (Sold Separately)
Rear Track: 12.75 in (323.8mm)
Servos: Not Included
Shock Type: Oil-Filled/Coil-Over Spring
Size/Scale: 1/10
Speed Control: (Sold Separately)
Suspension: Independent Front/4-Link Rear
Tire Diameter: 5.75 in (146mm)
Tire Tread: Maxxis Creeper Crawler LT
Track: 12.75 in (323.8mm)
Vehicle Type: Rock Racer
Weight: 6.55 lb (3.0kg)
Wheel Diameter: 2.2 in (55.9mm)
Wheel Hex Size: 12mm Hex
Wheel Type: 2.2 in (55.9mm) Glue-Type
Wheel Width: 1.6 in (40.75mm)
Wheelbase: 15.0 in (381mm)
Width: 12.75 in (323.8mm)Product Videos
Build It Your Way:Features Overview
You call the shots and build the Rock Rey any way you want.
4WD Independent Front Suspension with Solid 4 Link Rear Axle:
Scale looks and amazing performance over rough terrain.
Option Parts Included:
Kit includes aluminum rear upper links and upper rod track mount, as well as adjustable camber links and turnbuckles for steering.
Rear-Loading Battery Door:
Quick battery changes-no body clips need to be removed whatsoever.
Aluminum Chassis and Injection Molded Composite Roll Cage:
These enhance the Rock Rey’s durability and scale appearance.
LED Light Bar:
Drive into the night with the 12 LED light bar, which is powered by the receiver.
Metal Inserted Servo Horns:
Three metal servo horn inserts support 23, 24 and 25 tooth spline servos so you can use any servo you want and provide excellent durability.
2.2" x 5.8" Maxxis Creepy Crawler LT Tires:
These enhance the scale looks and provide aggressive tread for all-terrain applications.
HD Metal Gear Transmission:
The HD metal gear transmission provides a robust drivetrain.
Headlight Receptors:
The kit includes headlight receptors already in place-all you need to do is add your own LEDs.
Preset Motor Plate:
Different pinion choices offer precise and easy mesh settings.- Specs
Product Specifications
Part Number LOS03016 Scale 1/10 Drivetrain 4WD Kit Type Unassembled Kit Approximate Assembly Time 10-15 Hours Ball Bearings Yes Batteries 2S 5000mAh LiPo with EC3⢠Connectors (Sold Separately) Body Clear, Polycarbonate Brakes Electronic Charger (Sold Separately) Chassis 3.5mm Plate, 6061-T6 Aluminum Completion Level Kit Differential Locked Rear, Gear Diff Front and Rear-Sealed Drivetrain 4WD Front Track 12.75 in (323.8mm) Gear Pitch 1.0 Module Ground Clearance 2.2 in (55.9mm) at rear diff Height 8.75 in (222.3mm) Length 20.75 in (527mm) Motor Size 550 (Sold Separately) Motor Type Non-Sensored Brushless (Sold Separately) Pinion 10T Radio (Sold Separately) Rear Track 12.75 in (323.8mm) Servos Not Included Shock Type Oil-Filled/Coil-Over Spring Size/Scale 1/10 Speed Control (Sold Separately) Suspension Independent Front/4-Link Rear Tire Diameter 5.75 in (146mm) Tire Tread Maxxis Creeper Crawler LT Track 12.75 in (323.8mm) Vehicle Type Rock Racer Weight 6.55 lb (3.0kg) Wheel Diameter 2.2 in (55.9mm) Wheel Hex Size 12mm Hex Wheel Type 2.2 in (55.9mm) Glue-Type Wheel Width 1.6 in (40.75mm) Wheelbase 15.0 in (381mm) Width 12.75 in (323.8mm) - Reviews
