- Overview
features
- Zero timing firmware for ROAR SPORTMAN races and other fair races.
- World's Smallest footprint & Lightweight ESC ever. "23.5g"
- Programming/Upgrading/ Data Reading Wirelessly: Integrated Data logger can record the maximum temperature of ESC and motor as well as the maximum RPM.
- Built-in boost BEC with a maximum output of 6A and voltage adjustable between 6V and 7.4V for usage with high voltage servos.
- Separate PRG/FAN port is able to power an external fan for maximize cooling performance or connect a LCD program box or WiFi module to the ESC.
- With HOBBYWING WIFI express module, users are able to program parameters, upgrade firmware and check relevant data during the event using either the iphone or Android devices.
- New brakes and throttle functions: 100 levels of brag brake, 50 levels of initial brake force, 9 levels of maximum brake force, 20 levels of brake rate, and 30 levels of throttle rate. • Adjustable brake mode, PWM and brake frequencies and for different competitions and control feel.
- Adjustable Turbo Timing & Boost Timing for different applications.
- Multiple protections: low-voltage cutoff protection, ESC and motor thermal protection, and fail safe (throttle signal loss protection).
- Data logging for recording the maximum ESC/motor temperature, motor speed/RPM, and others in real time.
Cont./Peak Current: 80A/380ASpecs
Input Voltage: 1S Lipo/3-4 Cell NiMH
BEC Output: 6V/7.4V@3A
Wires: Black-14AWG-200mm
Connectors: No
ESC Programing: LCD Program Box or WiFi Module
Firmware Upgrade Supported: Yes
Size: 31.6x25.8x16.2mm
Weight: 23.5g (w/o Wires)
Applications: Stock 1S class of 1/10th & 1/12th on-road racing.
KV Rating/T Count: ≥10.5T, 3650-size Motor- Specs
Product Specifications
Part Number HWI30112751 Cont./Peak Current 80A/380A Input Voltage 1S Lipo/3-4 Cell NiMH BEC Output 6V/7.4V@3A Wires Black-14AWG-200mm Connectors No ESC Programing LCD Program Box or WiFi Module Firmware Upgrade Supported Yes Size 31.6x25.8x16.2mm Weight 23.5g (w/o Wires) Applications Stock 1S class of 1/10th & 1/12th on-road racing. KV Rating/T Count ≥10.5T, 3650-size Motor - Reviews
