- Overview
features
- Super built-in BEC with the peak output current of up to 15A and switchable output voltage of 6V/7.2V;
- Advanced electronic switch with the lifespan of over 50000 times of switching on & off;
- High-efficiency heat-dissipating system;
- Special dynamic timing control program is available when this ESC runs in full-sensored mode* ;
- Innovative coasting function (patent pending)
- ESC customization by a LCD program box (Purchase separately) or Wifi Express Module (Purchase separately)
Cont./Peak Current: 150A/950ASpecs
Motor Type: Sensored / Sensorless Brushless Motor
Main Applications: 1/8th Scale On-road, Buggy, Truggy for High-level Races
Motor Limit:
- 3S LiPo / 9cell NiMH: 3660 size motor, KV≤4500
- 4S LiPo/12S NiMH: ≤ KV3000 for 4274 size
- 6S LiPo/18S NiMH: ≤ KV2400 for 4274 size
LiPo/NiMH Cells: (2) 2-6S LiPo, 6-18S NiMH
BEC Output: 6V/7.2V Switchable, Continuous Current of 6A (Switch-mode BEC)
Cooling Fan: Powered by the stable BEC output voltage of 6V/7.2V
Size/Weight: 58.7(L) x 48(W) x 36.9(H) / 127g (W/O Wires)
Programming Port: FAN/PRG Port
ESC programming: LCD Program box, WiFi module enabledProduct Videos
- Specs
Product Specifications
Part Number HWI30113300 Cont./Peak Current 150A/950A Motor Type Sensored / Sensorless Brushless Motor Main Applications 1/8th Scale On-road, Buggy, Truggy for High-level Races Motor Limit - 3S LiPo / 9cell NiMH 3660 size motor, KV≤4500 - 4S LiPo/12S NiMH ≤ KV3000 for 4274 size - 6S LiPo/18S NiMH ≤ KV2400 for 4274 size LiPo/NiMH Cells (2) 2-6S LiPo, 6-18S NiMH BEC Output 6V/7.2V Switchable, Continuous Current of 6A (Switch-mode BEC) Cooling Fan Powered by the stable BEC output voltage of 6V/7.2V Size/Weight 58.7(L) x 48(W) x 36.9(H) / 127g (W/O Wires) Programming Port FAN/PRG Port ESC programming LCD Program box, WiFi module enabled - Reviews
