- Overview
Overview
4 pole rotor for high torque, fast acceleration response and stable power output.
Special technology for temperature control implemented by this motor guarantees less heat more efficiency
CNC machined aluminum housing, high purity copper windings, advanced rotor structure, high-quality alloy steel output shaft, high-precision bearings for high durability and smoothness.
Turbo Timing Technology
Full Sensored mode (when paired with XR8 SCT ESC or XR8 plus ESC)
Adjustable Timing (Bi-Directional) 20-40 degrees
Advanced Hall Sensor System
The use of double insulated windings (240°C R-rated), NMB bearings from Japan, and the high-intensity adhesive (340°C) guarantees users the outstanding performance and super durability.features
- 4 pole rotor for high torque, fast acceleration response and stable power output.
- Special technology for temperature control implemented by this motor guarantees less heat more efficiency
- CNC machined aluminum housing, high purity copper windings, advanced rotor structure, high-quality alloy steel output shaft, high-precision bearings for high durability and smoothness.
- Turbo Timing Technology
- Full Sensored mode (when paired with XR8 SCT ESC or XR8 plus ESC)
- Adjustable Timing (Bi-Directional) 20-40 degrees
- Advanced Hall Sensor System
- The use of double insulated windings (240°C R-rated), NMB bearings from Japan, and the high-intensity adhesive (340°C) guarantees users the outstanding performance and super durability.
Pole: 4Specs
KV(No-load): 2600
R. (Ω): 0.0035
Current No-load(A: 6A
C.at the point of M.O.P *(A): 120
Motor D.&L(mm: Φ=42, L=68
LiPo(S): 2-6
Weight: 316g
Applicable: 1/8 OnRoad & GTProduct Videos
- Specs
Product Specifications
Part Number HWI30401905 Pole 4 KV(No-load) 2600 R. (Ω) 0.0035 Current No-load(A 6A C.at the point of M.O.P *(A) 120 Motor D.&L(mm Φ=42, L=68 LiPo(S) 2-6 Weight 316g Applicable 1/8 OnRoad & GT - Reviews
