- Overview
Overview
Gens Ace batteries have been proven within the Radio Control community to deliver reliable and consistent performance for all modelers alike. All Gens Ace batteries offer superior cell matching at the factory, and are extremely consistent in selecting matched cells after each and every batch produced. Additionally, low internal resistance (IR), offers modelers stable voltage output through the whole duration of the battery.
Notes:
DO NOT leave a battery in your model when charging
DO NOT leave lithium batteries unattended when charging
ALWAYS balance charge lithium battery
ALWAYS use a LiPo Safe charging bag/box
YOU MUST use a Li-Poly specific charger to charge lithium batteries (NiMH or NiCD only chargers WILL NOT WORK!)
YOU MUST not over discharge lithium battery packs
READ & UNDERSTAND the instructions carefully before operating this battery
NOTE: When using high energy Li-Polymer Batteries, please do not over-discharge or over-charge batteries as this will result in overheated batteries. Discharging capacity can't exceed 80% of the max capacity of the pack after full charging to ensure a good cycle performance. It is recommended to fully charge a brand new battery before using and only discharge the battery 50% for the first 5 cycles. Always monitor race time and/or set a low voltage warning on ESC (End voltage cannot be lower than 3.2v per cell). Do not use a battery that has too low a voltage. Do not expose batteries to sunshine or store/charge batteries at temperatures above 35°C or in a closed car. The high-temperature environment could cause damage to the pack or make it burst. If the battery becomes hot while fast charging, high current discharging, or racing, do not charge it until it has cooled completely. Wait about 20 mins, then inspect prior to recharging.features
- Automatic identification and recording of all battery parameters
- Automatic identification and recording of all battery parameters
- Balance plug with built-in chip and exclusive patented design technology
- Prevent overcharge
- Voltage status indicator
- Self-storage mode
Nominal Voltage: 15.2V (4S)Specs
Capacity: 5300mAh
Maximum Charge Rate: (Not Available
Discharge Rates
Continuous: 100C
Peak: (Not Available)
Cell Configuration: 4S1P
Watt Hours: 80.56Wh
ROAR Approved: No
Connectors
Battery: EC5
Balance: G-Tech Smart Connector
Dimensions (LxWxH): 5.4x1.8x1.9in (138x46.5x49mm)
Weight: 17.14oz (486g)- Specs
Product Specifications
Part Number GEA534S10E5GT Battery Chemistry LiHV Battery Voltage 15.2V Capacity mAh 5300mAh Discharge Rate 100C Nominal Voltage 15.2V (4S) Capacity 5300mAh Maximum Charge Rate (Not Available Continuous 100C Peak (Not Available) Cell Configuration 4S1P Watt Hours 80.56Wh ROAR Approved No Battery EC5 Balance G-Tech Smart Connector Dimensions (LxWxH) 5.4x1.8x1.9in (138x46.5x49mm) Weight 17.14oz (486g) - Reviews
