- Overview
This is the AC Powered Duratrax Li-24 2-4S LiPo/LiFe Balance Charger with Star Connector.
Includes:
- Balance Charger
- 18AWG Charging Cable with 4mm Banana Plugs Star Connector
- AC Power Cord
- Instructions
features
- CC/CV charge method with voltages customized for LiPo/LiFe batteries
- 1A, 2A, 3A selectable charge current
- Star plug is compatible with the R/C industry's most commonly used
- polarized power plug, tapered shape and grip strips for fast and
- easy connection and separation
- Built-in balancing function ensures all cells are charged to
- maximum voltage
- One year limited warranty through Hobby Services beginning at date of
- purchase (U.S.A. and Canada only)
AC Input: 100-240V AC, 60Hz, U.S. plugSpecs
Output Power: 30W
Battery Type: LiPo/LiFe
Cells: 2-4
Fast Charge Start: Auto start at hook up
Fast Charge Current: 1A, 2A, 3A*
*Note, maximum charge current for a 4S pack will be 1.4A.
Maximum Charge Current: 3A
Balance Current: 200mA
Controls: Auto-start, switchable current selector
Output Connectors: 4mm banana sockets
Display Type: 4 red cell LEDs, 1 multi-colored status LED
Balancing Connector: Electrifly 2-4S
Dimensions: 4.4 x 2.7 x 1.6" (111 x 69 x 41mm)
Weight: 6.2oz (176g)- Specs
Product Specifications
Part Number DTXP4255 Supported Chemistries LiPo, LiFE AC Input 100-240V AC, 60Hz, U.S. plug Output Power 30W Battery Type LiPo/LiFe Cells 2-4 Fast Charge Start Auto start at hook up Fast Charge Current 1A, 2A, 3A* Maximum Charge Current 3A Balance Current 200mA Controls Auto-start, switchable current selector Output Connectors 4mm banana sockets Display Type 4 red cell LEDs, 1 multi-colored status LED Balancing Connector Electrifly 2-4S Dimensions 4.4 x 2.7 x 1.6" (111 x 69 x 41mm) Weight 6.2oz (176g) - Reviews
