Duratrax Onyx Li-24 2-4S LiPo/LiFe Balance Charger with Star Connector


LOADING IMAGES
Duratrax Onyx Li-24 2-4S LiPo/LiFe Balance Charger with Star Connector
$109.99
This is the AC Powered Duratrax DTXP4255, Onyx Li-24 2-4S LiPo/LiFe Balance Charger with Star Connector.

Availability: Please call for availability
We might still have one laying around..

* Some of the items on this site are still being inventoried if you want to confirm the item is in stock please contact us.
Overview

This is the AC Powered Duratrax Li-24 2-4S LiPo/LiFe Balance Charger with Star Connector.

Includes:

  • Balance Charger
  • 18AWG Charging Cable with 4mm Banana Plugs Star Connector
  • AC Power Cord
  • Instructions

features

  • CC/CV charge method with voltages customized for LiPo/LiFe batteries
  • 1A, 2A, 3A selectable charge current
  • Star plug is compatible with the R/C industry's most commonly used
  • polarized power plug, tapered shape and grip strips for fast and
  • easy connection and separation
  • Built-in balancing function ensures all cells are charged to
  • maximum voltage
  • One year limited warranty through Hobby Services beginning at date of
  • purchase (U.S.A. and Canada only)

Specs

AC Input: 100-240V AC, 60Hz, U.S. plug
Output Power: 30W
Battery Type: LiPo/LiFe
Cells: 2-4
Fast Charge Start: Auto start at hook up
Fast Charge Current: 1A, 2A, 3A*
*Note, maximum charge current for a 4S pack will be 1.4A.
Maximum Charge Current: 3A
Balance Current: 200mA
Controls: Auto-start, switchable current selector
Output Connectors: 4mm banana sockets
Display Type: 4 red cell LEDs, 1 multi-colored status LED
Balancing Connector: Electrifly 2-4S
Dimensions: 4.4 x 2.7 x 1.6" (111 x 69 x 41mm)
Weight: 6.2oz (176g)
Specs

Product Specifications

Part NumberDTXP4255
Supported ChemistriesLiPo, LiFE
AC Input100-240V AC, 60Hz, U.S. plug
Output Power30W
Battery TypeLiPo/LiFe
Cells2-4
Fast Charge StartAuto start at hook up
Fast Charge Current1A, 2A, 3A*
Maximum Charge Current3A
Balance Current200mA
ControlsAuto-start, switchable current selector
Output Connectors4mm banana sockets
Display Type4 red cell LEDs, 1 multi-colored status LED
Balancing ConnectorElectrifly 2-4S
Dimensions4.4 x 2.7 x 1.6" (111 x 69 x 41mm)
Weight6.2oz (176g)
