- Overview
FEATURES Chassis: Molded composite plastic with battery strap that accomodates
NiMH or LiPo battery packs
Drive: Rear wheel
Motor: Reedy 3300kV brushless
Radio: XP2G 2.4GHz 2-channel with DS1903MG metal gear steering
servo
Electronic Speed Control: XP brushless with reverse and LiPo low
voltage cutoff
Body: Trimmed and painted pro buggy body with roll cage, driver, and
window nets
Differential: Heavy-duty sealed gear
Shocks: Blue aluminum body V2, oil filled
Wheels: KMC replica, black in color
Rear, Diameter: 3" (76mm), Width: 1.6" (41mm), Hex Size: 12mm
Front Diameter: 3" (76mm), Width: 1.2" (31mm), Hex Size: 12mm
Tires: Front, rectangular block pattern 1.5" (38mm) wide,
4.25" (108mm) diameter
Rear, soft compound racing pin tread 1.6" (42mm) wide
4.25" (108mm) diameter
Caster: Adjustable, caster/toe-in refers to the angle of the front
suspension when viewed from the side of the car in relation to the
chassis
Camber: Adjustable, camber refers to the angle of the tops of the
tires from vertical when viewed from front or behind vehicleINCLUDES RTR SC10B RS Short Course Truck with 2.4GHz Radio, Brushless Motor,
ESC, Wheels, Tires w/Foam Inserts, Painted Body, Instruction Manual
Roll Cage, Driver Figure and Window NetsREQUIREMENTS AA Batteries: Six for transmitter
Battery: 6-cell sub C w/Deans connector or 2S LiPo
Battery Charger: For selected battery
Track equipmentSPECIFICATIONS Vehicle,
Length: 18.8" (479mm)
Width: 11.5" (293mm)
Weight: 4lbs (1818g)
Wheelbase: 12.7" (324mm)
Internal Gear Ratio: 2.6:1
Body,
Length 13.5" (343mm)
Width: 5" (127mm) at widest point
Height: 5.6" (142mm)- Specs
Product Specifications
Part Number ASC9050 Scale 1/10 Drivetrain 2WD Kit Type RTR - Reviews
