- Overview
FEATURES Chassis: Extruded aluminum
Drive: Four wheel
Drive Type: Shaft driven with CVA center drive shafts and large 22mm
metal wheel drive hexes
Radio: Associated XP 3G 2.4GHz
Engine: Two stroke Associated AE 8.0cc (.50 cu in) with Pro-Start
electric starter, aluminum bodied slide valve carburetor, two-stage
foam air filter, reinforced mounting plate
Exhaust: Tuned pipe with header
Fuel Tank: Dual pickup for continuous fuel flow
Clutch: Aluminum, four-shoe high-performance, 20 tooth clutch bell
Transmission: Two-speed automatic with reverse
Ball Bearings: Fully equipped
Shocks: Eight oil-filled, composite body with coil-over spring
Main Gear: 49 tooth,
Gearbox: Sealed, front and rear
Differentials: Planetary geared
Brakes: Heavy duty single disk
Tires: 6.75" (165mm) diameter, 3.5" (89mm) wide all-terrain treaded
rubber
Wheels: Chrome plated plastic 22mm hex size
Body: Highly detailed painted pickup truck (NOTE: color scheme may
vary between samples)
Bumpers: Chrome plated front and rear
Suspension: Four wheel independent A-arm type
Ride Height: Adjustable
Caster: Adjustable, caster/toe-in refers to the angle of the front
suspension when viewed from the side of the car in relation to the
chassis
Camber: Adjustable, camber refers to the angle of the tops of the
tires from vertical when viewed from front or behind vehicle
Steering: Bell-crank
Brake: Single disc
Servo Saver: IncludedINCLUDES Associated MGT 8.0 GT 21 with 8 oil-filled shocks, .50 (8.0cc) engine
glow plug, Pro-Start electric starter, 20.25oz (600ml) fuel bottle,
foam air filter, painted lexan body, tires, foam inserts, wheels,
2.4GHz radio, 20 tooth clutch bell, 49 tooth spur gear, and
illustrated instruction manualREQUIREMENTS Radio Batteries: 12 AA size
Glow Starter Battery: 1 D size
6-cell stick pack and charger for the pro start system
Misc. Items: Building and track equipment
Fuel: 2-cycle glow fuel with 15%-30% nitromethane, 14% lubricant-
Most of the fuels we carry meet or exceed the lubricant content
required for optimum performance and maximum engine life. In the
past, the conventional lubricant content used in fuel was 18%. But
with new advanced technologies, fuels like Red Alert and O'Donnell
for example, have a better quality of lubricants even though the
percentages of lubricant content are lower. These high-tech
lubricants provide exceptional cooling and protection.SPECIFICATIONS Vehicle-
Length: 24.17" (614mm)
Width: 17.24" (438mm)
Height: Not Listed
Weight: 13lbs (5900g)
Wheelbase: 14.49" (368mm)
Ground Clearance: Not Listed
Tires: 6.75" (171mm) outside diameter - 3.25" (82mm) width
Body-
Length: 20.5" (521mm)
Width: 7.75" (197mm)
Height: 5.25" (133mm)- Specs
Product Specifications
Part Number ASC20502 Scale 1/8 Kit Type RTR - Reviews
