- Overview
FEATURES Chassis: 0.12" (3mm) thick 7075-T6 hard-anodized aluminum, with
optimized weight bias layout for improved handling and stability
Drive: Four wheel shaft with six universal driveshafts
Differentials: New V2 geared design for longer life, fast access for
quick removal and tuning
Gearboxes: 4.6:1 internal ratio
Body: Pro-Line RC8T3e clear body, Team Associated rear wing molded in
black
Shocks: 7076-T6 aluminum bodied 16mm Big Bore threaded with TiN
coated 3.5mm diameter shafts, larger diameter springs, and
optimized bladders for more precise volume compensation
Shock Towers: 7076-T6 aluminum
Front Suspension: Pillow ball uprights for increased adjustability
and durability
Rear Suspension: Refined geometry with lower hinge pin inserts for
quick and easy roll center adjustments
Motor Mount: Two-piece sliding design for easy gear mesh adjustment
and motor removalINCLUDES RC8T3e Truggy Kit with Clear Body, Shocks, Decals, Shock Oil, Diff
Oil, and Instruction ManualREQUIREMENTS Radio: 2-channel with high torque steering servo
Motor and ESC: For 1/8 scale truggy applications, NOTE if using
the Novak Activ8 system listed in the accessory guide, connectors
must be soldered to the battery leads of the ESC to match selected
battery
Battery: 4S 14.8V, at least 4000mAh
Battery Charger: Compatible with selected battery
Wheels: 1/8 scale truggy
Tires: 1/8 scale truggy
Tools and track equipmentSPECIFICATIONS Vehicle;
Length: 22" (560mm)
Width: Varies
Weight: Varies
Wheelbase: 14.82" (376.5mm)
Body;
Length: 16.2" (412mm)
Width: 7.5" (190mm) at widest point
Height: 3.6" (91mm)- Specs
Product Specifications
Part Number ASC80918 Scale 1/8 Drivetrain 4WD Kit Type Unassembled Kit - Reviews
